HPL Laminated MGO Board for Interior Furniture
HPL Laminated MGO Board for Interior Furniture is used magnesium oxide board as substrate material, and compounded with gluing
melamine paper to MGO BOARD.
It combines the advantages of MgO board and melamine paper, and is an innovative decorative wall material.
High quality hpl laminated mgo board decorative insulation mgo board is widely used for interior decoration and furniture
|Face||HPL one face or two faces|
|HPL surface||Matt, Glossy, Relief, Grain, etc|
|Core material||Magnesium Oxide Board /Mgo board|
|HPL veneer thickness||0.5mm,0.8mm,1.0mm|
|1. Good visual effect, the panel can be made into different designs with vivid gloss.|
|2. Tough, abrasion-resistant, heat-resistant|
|3. Acid-resistant, alkali-resistant, oil-resistant|
|4. With smooth surface, easy to clean|
|5. Fireproof: Grade A non-combustible|
|7. Healthy and environmental friendly, doesn't contain asbestos, formaldehyde or benzene|
|Compressive Strength||~20 MPa (3, 000 PSI)|
|Impact Resistance||> 6 kJ/m2|
|Tensile Strength||> 5.5 MPa|
|Density (Specific Mass)||~1000 Kg/m3 (+/-< 2%)|
|Moisture Absorption||~26% maximum saturation (slow absorption rate)|
|Water Vapour Diffusion||~28 / 35|
|Specific Heat||~930 J/kgK|
|Thermal Conductivity||~0.44 W / mK|
|Modulus of elasticity||~6045 N/mm2|
UNI E 12372
|~20.1 N/mm2 maximum|
12mm x 1220 x 2440 = 10 N/mm2
|Surface Alkalinity||~10 Ph|
|Thermal Expansion Hot/Cold||0, 01 mm/mC (from temp +20C to -20C)|
|Expansion in Water||less than < 0.02% from ambient to saturation|
|Freeze / Thaw - UNI EN 520||100 cycles without notable effects|
|Frost Resistance||no water drops form on surface|
|Combustibility / Fire Ratings||non-combustible / 12mm exceeds 1 hr fire rating|
|Dimensional tolerance||thick 0.2mm / width 2mm / length 3mm / Sq. 3mm|
|Toxicity Pollutants Heavy Metals - UNI EN 12457-2||Below measurable levels of test instruments|
|Asbestos Analysis||Absent - not measurable|
|Formaldehyde Analysis||Absent - not measurable|
|Sound Attenuation (9mm)||tested design ASTM E90 = STC 48, 50, 55, & 60|
|Color||Slate Grey and Chalk White|
|Surface texture||smooth one side; uniform machine textured back|
|Basic Compounds||(MgO)+(natural silicates)+(glass fibre)+(wood fibre)|
Interior decoration used in furniture, cabinet, Marine,kitchen, bathroom, teapots, windowsills, interior wall panel and so on.
OCM(Oriental Construction Material) is a professional manufacturer of mgo products. This fireproof material can use from ceiling to flooring and everything in between.
Q:What's your delivery time?
A: 15-20 days after receive the deposit
Q: What's your payment?
A: T/T, 30% as sown payment and balance after B/L or irrevocable L/C
Q: Can you do customized product?
A: Yes, we can cut any sizes as required.
Q: What's your company production capacity?
A: We can produce 8000 sqm (10 mm) per day
Q: What's your MOQ? Can we order mixing different sizes?
A: Yes. MOQ is 100 pcs and mixed loading also acceptable.
